Remove/Install Rear Trim Strip On Window Frame Of Rear Door - AR72.12-P-1714SG

Model 223

with code Z07 (B7 armoring on special protection version)

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Remove lower trim strip at window frame of rear door.		AR72.12-P-1712S
2	Unclip rear trim strip (1).	Long wedge	Fig 1
3	Install in the reverse order.

Fig 1: Identifying Long Wedge (115 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
