Remove/Install Upper Trim Strip On Door Trim - AR72.12-P-1715S

Model 223

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Remove door trim (1).		AR72.12-P-1011S
2	Remove screws (3).
3	Release catch hooks (4) and remove trim strip (2).	Long wedge	Fig 1
4	Install in the reverse order.

Fig 1: Identifying Long Wedge (115 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
