Carry out delivery and allocation control - AP00.20-P-1100B

Model 117, 118, 156, 166, 167, 172, 176, 177, 190, 197.3/4, 204, 205, 207, 212, 213, 216, 217, 218, 221, 222, 231, 238, 242, 246, 247, 253, 257, 290, 292, 293, 461, 463

Courtesy of MERCEDES-BENZ USA

A	Z6	Z12		Input status not OK:		ⓧ
Carried out
√	√	√
↓	↓	↓			↓
□			The general protocol & delivery control for new vehicles has been completely processed.	Model 117, 118, 156, 166, 167, 172, 176, 177, 205, 213, 217, 222, 231, 238, 247, 253, 257, 290, 292, 293, 461, Model 463 The protocol Perform pre-delivery check. There are no open complaints.	◦	AP00.20-P-1101A
□			Car delivery controls can be found on the information and communication platform.	Only for Germany. Under "Search" enter the term "delivery control". All documents with a green box are valid. To be carried out by the service advisor.  Carry out a delivery check shortly before handing over the vehicle.
□			Vehicle on open Check customer service measures.	To be carried out by the service advisor.  If complaints are found, ↓ Carry out open customer service measures. Separate order.	◦
□			Confirm proof of delivery control in the DSB (digital service booklet).	Only in markets with DSB. To be carried out by the service advisor.
□			Make sure that the engine and transmission are running when the vehicle is moving.	If complaints are found, ↓ Perform error detection and advanced diagnostics. Separate order.	◦
□			Vehicle outer side, body (cleaned, transport protection approvals removed)  Check the condition of the wiper blades and the wiper pattern.	If complaints are found, ↓ Eliminate complaint. Separate order.	◦	AP82.30-P-8253G
□			Remove the protective film from the maintenance indicator on the wiper blades.	Vehicles with maintenance indicator on the washer blades.		AP82.30-P-8253G
□			Install covers on the towing items at the front.	Model 463.234 with code ZQ0 (G 500 4x42) Model 463.255 with code MUK 2 (vehicle type USA or Canada) Model 463 with code LQ0 (G650 Landaulet) Covers are included in the scope of delivery.
□			Engine compartment  Check engine oil level.	Engine 112, 113, 133, 139, 152, 156, 157, 159, 176, 177, 178, 254, 256, 260, 264, 270, 271, 272, 273, 274, 275, 276, 277, 278, 279, 282, 607, 608, 612, 626, 628, 629, 642, 646, 651, 654, 656	◦	AP18.00-P-1848U
				When checking the engine oil level via the instrument cluster, the engine oil temperature must be ≥ 60 ° C. Otherwise it can lead to an incorrect measurement and an incorrect amount of oil can be displayed.
□			Check the coolant level in the main circuit in the expansion tank.		◦	AP20.30-P-2049U
□			Check the coolant level of the low-temperature circuit in the expansion tank.	Model 167, 213, 217, 222, 290 with Engine 177 Model 463 with Engine 177	◦	AP20.30-P-2052F
□			Windscreen washer system: check fluid level, top up washer fluid if necessary.	When using cleaning additives for summer / winter depending on the ambient temperature, adhere to the proper mixing ratio.		AP82.35-P-8249U
□			Check all visible parts in the engine compartment for damage and leaks.	Model 117, 156, 176, 242, 246	◦	AP00.20-P-0055AK
				Model 166, 292		AP00.20-P-0055D
				Model 167		AP00.20-P-0055H
				Model 172, 197.3/4, 204, 207, 212, 216, 218, 221, 231		AP00.20-P-0055EW
				Model 118, 177, 247		AP00.20-P-0055I
				Model 190		AP00.20-P-0055B
				Model 205		AP00.20-P-0055C
				Model 213, 238, 253 (except 253.99), 257, 290		AP00.20-P-0055E
				Model 217, 222		AP00.20-P-0055A
				Model 253.99		AP00.20-P-0055G
				Model 293		AP00.20-P-0055J
				Model 461 Model 463 up to Model year 2019		AP00.20-P-0053AB
				Model 463 up to Model Year 2019		AP00.20-P-0055F
				Model 463 from Model Year 2019		AP00.20-P-0055GA
□			Tires, brakes  Check tire pressure, correct if necessary and enter measured values in the table, except for the spare wheel.	Model 117, 118, 156, 166, 167, 172, 176, 177, 190, 197.3/4, 204, 205, 207, 212, 213, 216, 217, 218, 221, 222, 231, 238, 242, 246, 247, 253, 257, 290, 292, 293 Model 463 from Model Year 2019	◦	AP40.15-P-4061A
				Model 461 Model 463 up to Model Year 2019		AP40.15-P-4060G
□			Assess the condition of the brake discs and enter the evaluation in the table.		◦	AP42.10-P-4249U
□			Tighten the wheel bolts.	Model 461, Model 463
□			Attach the hubcaps.	Vehicles with hubcaps. Make sure that the hubcaps are correctly positioned in relation to the valve and that they are firmly seated. Otherwise there will be damage to the valve or loss of the hubcaps and possibly further property damage.
			Vehicle underside
□			Remove the travel limiters.	Vehicles with travel limiters. Model 190		AP32.25-P-3270A
□			Check axle portals and axles for leaks.	Model 253.99 Model 463.234 with Code ZQ0 (G 500 4x42) Model 463.255 with Code MUK2 (Vehicle Model USA or Canada)	◦	AP32.25-P-3270B
□			Vehicle interior  Confirm vehicle handover in the instrument cluster.	Only for vehicles with mileage ≤ 250 km in the first month, with a stock vehicle from the maintenance notification or immediately before the vehicle is handed over to the customer
□			Check time setting of clock, adjust if necessary.		◦
□			Check function of the horn.		◦
□			Check warning and function lights in the instrument cluster.		◦
□	□	□	Check the charge status of the high-voltage battery.	Vehicles with high-voltage battery. If the state of charge (SOC) of the high-voltage battery is < 30%, ↓ bring the high-voltage battery to an SOC value of ≥ 50% charge.	◦	AP54.30-P-5449U
□			Transport mode  Deactivate transport mode and enter the remaining service life / standby of the battery in the table.	Vehicles with activated transport mode. Model 117, 156, 166.8, 176, 190, 205, 217, 218.9, 222, 231, 242, 253, 292, 293 Model 166.0, 172, 197.3/4, 204, 207.3/4, 212, 218.3, 246 from Model Year 2013	◦	AR54.00-P-0001A
				Model 118, 177, 247		AR54.00-P-0001MFA
				Model 167, 213, 238, 257, 290		AR54.00-P-0001LWE
□			Charge status in the menu Set "charging options & maximum charge level" to 100%.	Model 463 from Model Year 2019		AR54.00-P-0001XG
□			Check the charge status of the on-board power supply battery using the instrument cluster.	Model 293 vehicles without activated transport mode. Model 166.0, 172, 197.3 / 4, 204, 207, 212, 218, 246 up to Model Year 2013 Model 216, 221 If the charge level of the 12 V on-board power supply battery is below the permitted level, ↓ Charge the on-board power supply battery and then carry out a Midtronics test. Separate order.	◦	AR54.10-P-1132A
□			Miscellaneous  Deactivate transport level.	Vehicles with activated transport level.	◦
□			Enter other defects in the table.	Model 222 (except 222.179 / 187/188) from Model Year 2018 except Code 487 (MAGIC BODY CONTROL)	◦	AP32.30-P-3212A
	□		Additional work when vehicle has been sitting for more than 6 months  Replace brake fluid.	Model 117, 118, 156, 166, 167, 172, 176, 177, 190, 197.3/4, 204, 205, 207, 212, 213, 216, 217, 218, 221, 222, 231, 238, 242, 246, 247, 253, 257, 290, 292, 293, 461, Model 463
				Model 117, 156, 176, 242, 246		AP42.00-P-4280AK
				Model 166, 292		AP42.00-P-4280GZ
				Model 167		AP42.00-P-4280F
				Model 172, 231		AP42.00-P-4280V
				Model 118, 177, 247		AP42.00-P-4280E
				Model 190		AP42.00-P-4280B
				Model 197.3/4		AP42.00-P-4280RQ
				Model 204, 205, 207, 212, 218		AP42.00-P-4280EW
				Model 213, 238, 253, 257, 290		AP42.00-P-4280C
				Model 216 Model 221.0/1		AP42.00-P-4280SX
				Model 217, 222		AP42.00-P-4280HA
				Model 293		AP42.00-P-4280G
				Model 463 up to Model Year 2019		AP42.00-P-4280D
				Model 463.236/248 with Code 979 (MB Guard special protection package)		AP42.00-P-4280GS
				Model 463 from Model Year 2019		AP42.00-P-4280GA
		□	Additional work when vehicle has been sitting for more than 12 months  Replace AdBlue®.	Vehicle with AdBlue®. Model 118, 166, 167, 172, 177, 204, 205, 207, 212, 213, 218, 221, 222, 238, 247, 253, 257, 292, Model 463 Model 166 with Engine 642, 651 with Code U42 (Diesel emissions control BlueTEC (SCR)) Model 292 with Engine 642 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2014-02GQ
				Model 167 with Engine 654, 656 with Code U79 (Diesel emissions control BLUETEC (SCR) Generation 3)		AR49.20-P-2015OID
				Model 172 with Engine 651 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2014-02CDA
				Model 118, 177, 247 with Engine 608, 654 with Code U79 (Diesel emissions control BLUETEC (SCR) Generation 3)		AR49.20-P-2015MFE
				Model 205, 253 with Engine 651 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2014-02LWB
				Model 205 with Engine 654		AR49.20-P-2015OLI
				Model 207 with Engine 642 with Code U77 (Diesel emissions control BLUETEC (SCR)) Model 207 with Engine 651 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2014-02ECM
				Model 212, 218 with Engine 642 with Code U77 (Diesel emissions control BLUETEC (SCR)) Model 212, 218 with Engine 651 with Code U77 (Diesel emissions control BLUETEC (SCR)) Model 212, 221 with Engine 642 with Code U42 (Diesel emissions control BlueTEC (SCR))		AR14.40-P-2014-02GZB
				Model 213, 238 with Engine 654 with Code U79 (Diesel emissions control BLUETEC (SCR) Generation 3) Model 213, 238, 253 with Engine 642 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2068OGW
				Model 213, 238, 257 with Engine 656 with Code U79 (Diesel emissions control BLUETEC (SCR) Generation 3) Model 257 with Engine 654 with Code U79 (Diesel emissions control BLUETEC (SCR) Generation 3)		AR49.20-P-2015OIB
				Model 222 with Engine 642 with Code U77 (Diesel emissions control BLUETEC (SCR))		AR14.40-P-2014-02LF
				Model 222 with Engine 656		AR49.20-P-2014-01OIA
				Model 222 with Engine 656 with filling device		AR49.20-P-2014-02OIA
				Model 222 with Engine 656 with refill canister		AR49.20-P-2014-02OIB
				Model 463.306/336/346/348 with Engine 642		AR14.40-P-2014-02G
				Model 463 with Engine 656 from Model Year 2019		AR49.20-P-2015XGE
		□	Engine: change the oil and filter.			AP18.00-P-1846U
