Remove/Install Emergency Call System Backup Antenna - AR82.95-P-0018LWT
Model 213.2
with code 362 (HERMES communications module LTE)
| Risk of injury caused by fingers being jammed or pinched when removing, installing or aligning hoods, doors, trunk lid/rear-end door or sliding roof. | No parts of the body or limbs should be within the operating area when the components are moving. | AS00.00-Z-0011-01A | |
| Information on preventing damage to electronic components due to electrostatic discharge | AH54.00-P-0001-01A | ||
| Notes on HANDS-FREE ACCESS | AH80.61-P-0001-01A | ||
| Remove/install | |||
| 1 | Remove roof spoiler | AR82.10-P-5376LWT | |
| 2 | Disconnect electrical connector (3) and unclip electrical line (1) | ||
| 3 | Release emergency call system antenna 2 (A2/141) (arrows) and unfasten from liftgate (2) | ||
| 4 | Install in the reverse order |
