Remove/Install Center Air Vent - AR83.10-P-4503RG

Model 190

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Unclip cover (2) under center air vent (1)	Mounting wedge	Fig 1
2	Disconnect electrical connector from Bluetooth® antenna		AR82.62-P-8980RG
3	Remove bolt (3)
4	Pull out center air vent (1) and remove
5	Install in the reverse order

Fig 1: Identifying Mounting Wedge (110 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
