Remove/Install Fender Liner In Rear Fender - AR88.10-P-1400RGB

Model 190

with code M032 (Black Series version)

Courtesy of MERCEDES-BENZ USA

	Risk of death  caused by vehicle slipping or toppling off of the lifting platform.	Align vehicle between vehicle lift columns and position the four support plates at the vehicle lift support points specified by the vehicle manufacturer.	AS00.00-Z-0010-01A
	Risk of injury  . Skin or eye injuries may result when handling hot or glowing objects.	Wear protective gloves, protective clothing and safety glasses, if necessary.	AS00.00-Z-0002-01A
	Risk of injury  caused by scraping or cutting body parts on sharp vehicle parts	Always wear protective gloves when working on or near sharp and non-deburred vehicle parts. Deburr repair panels.	AS00.00-Z-0017-01A
	Remove/install
1	Remove the rear left/right wheel and tire assembly.		AR40.10-P-1100RQ
2	Remove nuts (2).
3	Remove screw (6).
4	Remove expansion rivets (7).	Clip remover	Fig 1
5	Remove nuts (3).
6	Remove expansion rivets (4).	Clip remover	Fig 1
7	Remove screws (5).
8	Detach the fender liner (1) on the left/right from the fender, longitudinal member panel and rear bumper and remove.
9	Install in the reverse order.

Fig 1: Identifying Clip Remover (452 589 01 63 00)
