Overview of system components, attention assist - GF54.30-P-9991CA
MODEL 207 up to model year 2014
| Component description for instrument cluster | A1 | GF54.30-P-6000CA | |
| Component description for the radio | MODEL 207 up to model year 2014 with CODE 510 (Audio 20 with CD changer) MODEL 207 up to model year 2014 with CODE 523 (MB Audio 20 radio) A2 |
GF82.60-P-3122CAA | |
| Component description for radio with auto pilot system | MODEL 207 up to model year 2014 with CODE 511 (Audio 50 APS with DVD changer) MODEL 207 up to model year 2014 with CODE 525 (MB Audio 50 APS radio) A2/56 |
GF82.61-P-4112CAA | |
| Component description for COMAND controller unit | MODEL 207 up to model year 2013 with CODE 512 (COMAND APS with DVD changer) MODEL 207 up to model year 2013 with CODE 527 (COMAND APS with single DVD drive (with navigation)) without CODE 498 (Japanese version) A40/3 |
GF82.85-P-3136CA | |
| MODEL 207 up to model year 2013 with CODE 526 (COMAND with single DVD drive (without navigation)) MODEL 207 up to model year 2013 with CODE 528 (COMAND with DVD changer) A40/3 |
GF82.85-P-3136CAA | ||
| MODEL 207 as of model year 2013 up to model year 2014 with CODE 512 (COMAND APS with DVD changer) MODEL 207 as of model year 2013 up to model year 2014 with CODE 527 (COMAND APS with single DVD drive (with navigation)) MODEL 207 as of model year 2013 up to model year 2014 with CODE 528 (COMAND with DVD changer) A40/3 |
GF82.85-P-3136CAB | ||
| MODEL 207 up to model year 2014 with CODE 498 (Japanese version) with CODE 527 (COMAND APS with single DVD drive (with navigation)) A40/3 |
GF82.85-P-3136CAJ | ||
| Component description for yaw rate sensor for lateral and longitudinal acceleration | B24/15 | GF42.45-P-4810CA | |
| Component description for front SAM control unit with fuse and relay module | N10/1 | GF54.21-P-6070CA | |
| Component description for Electronic Stability Program control unit | N30/4, N30/7 | GF42.45-P-5119CA | |
| Component description for the electronic ignition lock control unit | N73 | GF80.57-P-6001CA | |
| Component description for steering column tube module control unit | N80 | GF54.21-P-6051CA | |
| Table of contents for function description, attention assist | GF54.30-P-0992CA |
