Fill Adblue(R) Tank - AP49.20-P-0100A
Model 118, 167, 177, 247, 257 with code U79 (BLUETEC (SCR) diesel exhaust treatment, generation 3)
Model 463
as of model year 2019
with code M020 (BLUETEC)
External filling, shown on model 177.0 with engine 608.9
| Risk of burn injuries and scalding when working at AdBlue lines and the components attached to them. Risk of injury to skin and eyes when handling AdBlue. Risk of poisoning caused by swallowing AdBlue | Pour AdBlue into suitable containers only. Wait until the pressure is released before starting any work on the exhaust aftertreatment system. | AS14.40-Z-0001-01A | |
| Notes on use, material properties and handling of AdBlue(R) for service | AH14.40-P-0001-02A | ||
| 1 | Filling fill AdBlue® container. | AP49.20-P-0100-02A | |
| One-way filling hose | *BR00.45-Z-1001-17A | ||
| 10 l can of AdBlue® | *BR00.45-Z-1003-17A |
REPAIR MATERIALS
| Number | Designation | Order number |
|---|---|---|
| BR00.45-Z-1001-17A | One-way filling hose | A 000 583 22 04 |
| BR00.45-Z-1003-17A | 10 l can of AdBlue® | A 004 989 04 20 12 |
