Remove/install front differential mount on rear axle carrier - AR35.10-P-0051CW

MODEL 204, 207 (except 204.9)

Fig 1: Identifying Rear Axle Carrier, Rear Muffler, Differential Mount, Adjusting Disk And Differential

Courtesy of MERCEDES-BENZ USA

	Remove/install
		While working on the rear axle care must be taken to ensure that the surfaces of all aluminum components do not get any scratches, cracks and notches. Otherwise the service life of the of the parts will be reduced.
1	Remove left and right rear diagonal strut	Model 207.4	*BA61.10-P-1007-01H  *BA61.10-P-1008-01H  *BA61.10-P-1009-01H
2.1	Remove rear muffler (6)	Engine 271, 272, 273, 276, 278 Engine 642, 646, 651	AR49.10-P-7100CW AR49.10-P-7100CWI
2.2	Detach exhaust system at connecting point of catalytic converter/center muffler and remove	Engine 156	AR49.10-P-7100CW
3	Lower rear axle carrier (4) at front		AR35.10-P-0015CW
4	Detach differential (50) from differential mount (8)	Installation:  The adjusting disk (9) must be reinstalled.	*BA35.10-P-1005-01N
5	Detach differential mount (8) from rear axle carrier (4) and remove		*BA35.10-P-1004-01N
6	Install in the reverse order

REAR AXLE CARRIER

Number	Designation		Model 204	Model 207
BA35.10-P-1004-01N	Bolt, adapter to front crossmember	Nm	150	150
BA35.10-P-1005-01N	Differential to front adapter	Nm	65	65

FRAME FLOOR ASSEMBLY

Number	Designation		Model 207.4
BA61.10-P-1007-01H	Bolt, rear diagonal strut on spare wheel well	Nm	80
BA61.10-P-1008-01H	Bolt, rear diagonal strut on longitudinal member	Nm	80
BA61.10-P-1009-01H	Bolt, rear diagonal strut to bracket	Nm	17
