Remove/install button unit on multifunction steering wheel - AR54.25-P-2840TX
MODEL 230.4 up to 28.1.08 except CODE (809) Model year 2009
| Remove/install | |||
| 1 | Remove driver air bag unit (1) | AR91.60-P-0660R | |
| 2 | Undo screws (2) and remove contact plate (3) | *BR00.45-Z-1059-02A | |
| *BA91.60-P-1018-01A | |||
| 3 | Undo screws (4) and remove printed circuit board (5) | ||
| 4 | Remove left multifunction steering wheel button group (S110) or right multifunction steering wheel button group (S111) at side from driver air bag unit (1) | ||
| 5 | Install in the reverse order |
AIRBAG
| Number | Designation | Model 230 | |
|---|---|---|---|
| BA91.60-P-1018-01A | Bolt, contact plate to airbag | Nm | 5 |
REPAIR MATERIALS
| Number | Designation | Order number |
|---|---|---|
| BR00.45-Z-1059-02A | Loctite 262 | Henkel Loctite Deutschland GmbH Arabellastrasse 17 81925 Munchen Germany Tel. +49 899268-0 Fax + 49 899101978 www.Loctite.de |
