Remove/install seat belt for luggage and load securing in the rear - AR91.40-P-1143R

MODEL 230 except CODE (P99) "AMG Black Series" special model

Fig 1: Identifying Seat Belt Components For Luggage And Load Securing

Courtesy of MERCEDES-BENZ USA

	Remove/Install
1	Remove interior paneling at rollover bar		AR68.30-P-1380R
2	Disconnect electrical connector (2) from the speakers
3	Unscrew bolts (3)		*BA68.50-P-1001-03B
4	Remove seat belt for securing suitcases and loads in rear (1) from rear wall
5	Install in the reverse order

CARGO RETAINERS

Number	Designation		Model 230
BA68.50-P-1001-03B	Bolt for load belt console to rear wall	Nm	8
