Removing and installing air intake - AR83.25-P-1401E

MODEL 202, 208

Fig 1: Identifying Air Intake Remove/Install Components

REVISIONS

15.2.96

Special tool added

	Removal, installation
1	Remove cover on left and right air intake		AR83.25-P-1400E
2	Unscrew hex. nuts (17)
3	Unscrew screws (14)
4	Disconnect outside temperature sensor connector (B10/5x1)	Model 202 up to 31.08.95 with air conditioning (automatic) (code 581a) or air conditioning (code 580)
5	Unclip 12 hooks (16)		Fig 2
6	Remove air intake
7	Reinstall in opposite order

Fig 2: Identifying Removal Tool (202 589 00 61 00)
