Front Oil Seal Replacement: Notes

WARNING: This page is about a different variant/trim than selected.
  1. Disconnect the negative battery cable.
  2. Remove the engine cover. (See ENGINE COVER REMOVAL/INSTALLATION .)
  3. Remove the both front wheels and tires (RH). (See GENERAL PROCEDURES (SUSPENSION) .)
  4. Remove the splash shield (RH).
  5. Remove the generator and A/C drive belt. (See DRIVE BELT REMOVAL/INSTALLATION .)
  6. Remove the power steering oil pump drive belt. (See DRIVE BELT REMOVAL/INSTALLATION .)
  7. Remove in the order indicated in the table.
  8. Install in the reverse order of removal.
    Fig 1: Power Steering Oil Pump Components With Torque Specifications
    G08140351
