Rear Door Latch And Lock Actuator Inspection

WARNING: This page is about a different car, the 2009 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

The following actuator and switch are integrated with the rear door latch and lock actuator. Inspect the rear door latch and lock actuator according to each inspection procedure for the following items.
- Rear door lock actuator (See REAR DOOR LOCK ACTUATOR INSPECTION .)
- Rear door latch switch (See REAR DOOR LATCH SWITCH INSPECTION )
- Rear door lock-link switch (Vehicles with theft-deterrent system) (See DOOR LOCK-LINK SWITCH INSPECTION .)

Fig 1: Identifying Rear Door Latch And Lock Actuator Circuit With Connector - LH

Courtesy of MAZDA MOTORS CORP.

Fig 2: Identifying Rear Door Latch And Lock Actuator Circuit With Connector - RH

Courtesy of MAZDA MOTORS CORP.
