Removal [12/2023 - ]: Procedure

WARNING: This page is about a different car, the 2024 Lexus TX 550h+ and 2024 Lexus TX 500h. However, it is still accessible from the selected car via links, so may be relevant.
  1. PRECAUTION
    NOTE:

    After the ignition switch is turned off, there may be a waiting time before disconnecting the negative (-) auxiliary battery terminal.

    Refer to BEFORE DISCONNECTING BATTERY [09/2023 - ]

    Refer to PRECAUTION [09/2023 - ]

  2. CHECK FOR DTC
    1. Check for DTCs.
      WARNING:
      • Confirm that DTC P0AA6-49 (Hybrid / EV Battery Voltage System Isolation Internal Electronic Failure), P1C7C-49 (Hybrid / EV Battery Voltage System Isolation (A/C Area) Internal Electronic Failure), P1C7D-49 (Hybrid / EV Battery Voltage System Isolation (Hybrid/EV Battery Area) Internal Electronic Failure), P1C7E-49 (Hybrid / EV Battery Voltage System Isolation (Transaxle Area) Internal Electronic Failure) or P1C7F-49 (Hybrid / EV Battery Voltage System Isolation (Direct Current Area) Internal Electronic Failure), P1C80-49 (Hybrid/EV Battery Voltage System Isolation (Rear Motor Area) Internal Electronic Failure, for 4WD/AWD), P1CF7-49 (Hybrid/EV Battery Voltage System Isolation (Charger Area) Internal Electronic Failure), P33CF-49 (Hybrid/EV Battery Voltage System Isolation Internal Electronic Failure Abnormal Area Detection Failure) is not output before removing or installing the HV battery. If this DTC is output, perform troubleshooting for this DTC first.
        GTY588421Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      • To reduce the risk of electric shock, do not perform troubleshooting before checking for DTCs.
  3. REMOVE DECK BOARD ASSEMBLY

    Refer to PROCEDURE - Step 2

  4. REMOVE BATTERY SERVICE HOLE COVER

    Refer to PROCEDURE - Step 3

  5. DISCONNECT CABLE FROM NEGATIVE AUXILIARY BATTERY TERMINAL

    Refer to PROCEDURE - Step 4

  6. REMOVE BATTERY SERVICE HOLE COVER
    1. GTY1228604Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  7. REMOVE REAR FLOOR SERVICE HOLE COVER
    1. GTY1228605Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  8. REMOVE NO. 2 TRACTION BATTERY COVER
    1. GTY1228602Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  9. REMOVE NO. 1 HYBRID BATTERY SEAL
    1. GTY1080155Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  10. REMOVE SERVICE PLUG GRIP
    WARNING:
    • Be sure to wear insulated gloves.
    • Do not inspect or service the high voltage system with the service plug grip installed.
      GTY606173Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    • To reduce the risk of electric shock, make sure to remove the service plug grip to cut off the high voltage circuit before servicing the vehicle.
    • GTY577295Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

      To reduce the risk of electric shock, make sure to wait at least 10 minutes after removing the service plug grip to fully discharge the high voltage capacitor inside the inverter with converter assembly.

    • Keep the removed service plug grip in your pocket to prevent other technicians from accidentally installing it while you are servicing the vehicle.
    NOTE:
    • After removing the service plug grip, turning the ignition switch to ON (READY) may cause a malfunction. Do not turn the ignition switch to ON (READY) unless instructed by the appropriate service information .
    • Do not touch the terminals of the service plug grip.
    • If the service plug grip has been struck or dropped, replace it.
    HINT: Waiting for at least 10 minutes is required to discharge the high voltage capacitor inside the inverter with converter assembly.
    1. Fig 1: Service Plug Grip Removal Sequence
      GTY1237800Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      1. While wearing insulated gloves, rotate the handle of the service plug grip and remove the service plug grip as indicated by the arrows, in the order shown in the illustration.
        WARNING:
        • Do not allow any foreign matter to fall into the HV supply battery assembly.
        • Take steps to prevent foreign material from falling into the HV supply battery assembly after removing the service plug grip.
  11. TEMPORARILY INSTALL NO. 2 TRACTION BATTERY COVER
    1. GTY1228602Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
