DTC B2035: Power Supply Relay Adherence Malfunction: Wiring Diagram

Fig 1: Identifying Power Supply Relay Adherence Malfunction Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

NOTE: When the seat belt control ECU is replaced with a new one, INITIALIZATION must be performed. (See INITIALIZATION  )
