Rear Engine Mount Bracket - DDCT

REMOVAL

1. Raise and support the vehicle. Refer to HOISTING, STANDARD PROCEDURE .
2. Remove the belly pan. Refer to BELLY PAN, REMOVAL AND INSTALLATION .

   Courtesy of CHRYSLER GROUP, LLC

3. Support the powertrain with a suitable jack.
4. Remove the bolt (1) from the rear engine mount isolator.
5. Remove the bolts (2) and the rear engine mount bracket.

INSTALLATION

Courtesy of CHRYSLER GROUP, LLC

1. Install the rear engine mount bracket and tighten the bolts (1) to the proper torque specification. Refer to TORQUE SPECIFICATIONS  .
2. Install the rear engine mount isolator bolt (2) and tighten to the proper torque specification. Refer to TORQUE SPECIFICATIONS  .
3. Install the belly pan. Refer to BELLY PAN, REMOVAL AND INSTALLATION .
4. Remove the support and lower the vehicle.
