Doors - Rear: Channel-Glass: Removal

Fig 1: Remove/Install Watershield
GC0044916Courtesy of DAIMLERCHRYSLER CORP.
  1. Remove the watershield. (Refer to BODY/DOORS - REAR/WATERSHIELD - REMOVAL)
    Fig 2: Remove/Install Glass Channel
    GC0044918Courtesy of DAIMLERCHRYSLER CORP.
  2. Remove the weatherstrip from the rear glass run channel (2).
  3. Loosen the bolt (2) that secures the top of the rear glass run channel to the keyed hole on the inside door panel.
  4. Remove the nut (4) that secures the bottom of the run channel to the inside door panel.
  5. Remove the rear glass run channel from the door.
