Front Tow Hook: Removal
WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Front fascia must be removed to replace the stud plate. (Refer to FRAME & BUMPERS/BUMPERS/FRONT FASCIA - REMOVAL)
- Remove the nuts and bolt and remove the tow eye/hook. See Fig 1.
| 1 - STUD PLATE |
| 2 - U-NUT |
| 3 - BOLTS |
| 4 - NUTS |
| 5 - TOW HOOK |
| 6 - TOW EYE |
