Rear Floor Heat Duct: Removal
WARNING: This page is about a different car, the 2005 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the floor console (Refer to BODY/INTERIOR/FLOOR CONSOLE - REMOVAL) .
- Remove the screw that secures the rear floor heat duct to the floor console bracket. See Fig 1.
- Disengage the rear floor heat duct from the floor distribution duct.
- Remove the rear floor heat duct from the vehicle.
| 1 - REAR FLOOR HEAT DUCT |
| 2 - SCREW |
| 3 - CONSOLE BRACKET |
| 4 - TRANSMISSION SHIFT LEVER ASSEMBLY |
| 5 - FLOOR DISTRIBUTION DUCT |
