Airbag Supplementary Restraint System (G1818071): Description: PRETENSIONERS

WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
G14011897Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

A pyrotechnic pretensioner is integrated into each seatbelt retractor. The pretensioners are used to tighten the seatbelts during a collision to ensure the occupants are securely held in their seats.

When operated by the RCM, the pretensioners rotate the spool holding the end of the webbing to tighten the seatbelt.
