Front Center Seat Replacement

WARNING: This page is about a different car, the 2007 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Front Center Seat Replacement

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the front seats. Refer to Seat Replacement .
1	Bolt, Front Center Seat Assembly (Qty: 4) Tighten: 9 N.m (80 lb in)
2	Seat Assembly, Front Center Tip: Disconnect the electrical connectors.

Callout

Component Name

NOTE: Refer to Fastener Notice .

Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .

Preliminary Procedure

Disable the SIR system. Refer to SIR Disabling and Enabling .
Remove the front seats. Refer to Seat Replacement .

Bolt, Front Center Seat Assembly (Qty: 4)

Tighten: 9 N.m (80 lb in)

Seat Assembly, Front Center
Tip: Disconnect the electrical connectors.
