Rear Brake Caliper Bracket Replacement (J55)

WARNING: This page is about a different car, the 2007 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Brake Caliper Bracket Replacement - Rear (J55)

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
CAUTION: Refer to Brake Dust Caution . Preliminary Procedure Remove the brake caliper. Refer to Front Brake Caliper Replacement (J55) or Front Brake Caliper Replacement (JL9) . Remove the brake pads. Refer to Rear Disc Brake Pads Replacement (J55) or Rear Disc Brake Pads Replacement (JL9) .
1	Bracket Bolt (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 163 N.m (120 lb ft)
2	Spacer (Qty: 2)
3	Brake Caliper Bracket
