Rear Compartment Lid Hinge Replacement

WARNING: This page is about a different car, the 2007 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Hinge Replacement - Rear Compartment Lid

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications Preliminary Procedure Remove rear compartment lid. Refer to Rear Compartment Lid Replacement . Remove Torque rods. Refer to Rear Compartment Lid Hinge Torque Rod Replacement .
1	Nut, Rear Compartment Hinge (Qty: 1) Tighten: 25 N.m (19 lb ft)
2	Bolts, Rear Compartment Lid Hinge (Qty: 2) Tighten: 25 N.m (19 lb ft)
3	Hinge, Rear Compartment
