Ignition Key Hole Illumination (Without Intelligent Key)

  1. Remove combination meter. Refer to "REMOVAL AND INSTALLATION OF COMBINATION METER ".
  2. Remove screw and remove NATS antenna amp.
  3. Pull out ring and turn bulb socket to left to release lock.

    Ignition key hole illumination : 12 V - 0.8 W

  4. Installation is the reverse order of removal.
    Fig 1: Identifying Combination Meter
    G04078398Courtesy of NISSAN MOTOR CO., U.S.A.
