Repair Procedures: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Turn the ignition switch OFF and disconnect the battery negative (-) terminal.
  2. Remove the crash pad lower panel.

    (Refer to Body - "CRASH PAD LOWER PANEL ")

  3. Remove the ISG OFF switch (A) after loosening the mounting screw.
G14525107Courtesy of HYUNDAI MOTOR AMERICA
