RDM Indicator (Amber)

WARNING: This page is about a different variant/trim than selected.

When the RDM system detects a problem, the RDM system stops working, then the RDM indicator and the brake system indicator (amber) stay on.

NOTE:

For locations of each indicator, refer to System Warning/Indicator Index .
For RDM system function, review the Road Departure Mitigation System Description .
The RDM system communicates with other control units via F-CAN. For RDM system diagram, refer to the System Diagram for RDM . If a connected unit malfunctions, the RDM system will not operate. In this case, both RDM indicator and connected unit indicator come on and stay on (except for the gauge control module).
Some detected abnormalities may not turn on the brake system indicator.
