LKAS Indicator (Amber)
WARNING: This page is about a different variant/trim than selected.
When the LKAS detects a problem, the LKAS stops working, then the LKAS indicator stays on.
NOTE:
- For locations of the indicator, refer to System Warning/Indicator Index .
- For LKAS function, review the Lane Keeping Assist System (LKAS) Description .
- The LKAS communicates with other control units via F-CAN. For LKAS diagram, refer to the System Diagram for LKAS . If a connected unit malfunctions, the LKAS will not operate. In this case, both LKAS indicator and connected unit indicator come on and stay on (except for the gauge control module).
