ACC Indicator (Amber)

WARNING: This page is about a different variant/trim than selected.

When the ACC system detects a problem, the ACC system stops working, then the ACC indicator and the brake system indicator (amber) stay on.

NOTE:

For locations of each indicator, refer to System Warning/Indicator Index .
For ACC function, review the Adaptive Cruise Control (ACC) Description .
The ACC system communicates with other control units via F-CAN. For ACC system diagram, review the ACC System Diagram . If a connected unit malfunctions, the ACC system will not operate. In this case, both ACC indicator and connected unit indicator come on and stay on (except for the gauge control module).
Some detected abnormalities may not turn on the brake system indicator.
