Washer Tube Replacement

Remove the right inner fender (see FRONT INNER FENDER REPLACEMENT ).
Remove the washer nozzles and clips, then remove the tubes.
To install longer washer tubes routed inside the body, remove and replace them by joining the old tube to the new washer tube with a straight washer tube joint. Then pull the other end of the old washer tube out, pulling the new washer tube into position through the body with it.

Fig 1: Identifying Washer Tube (1 Of 2)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 2: Identifying Washer Tube (2 Of 2)
Courtesy of AMERICAN HONDA MOTOR CO., INC.
