Front End Spoiler Replacement (ATS-V Series)

WARNING: This page is about a different car, the 2017 Cadillac ATS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Rear End Spoiler (Sedan ATS- V)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Lifting and Jacking the Vehicle (ATS-V) Front Bumper Fascia Air Deflector Replacement - Outer (ATS-V Series)
1	Front End Spoiler Bolt (Qty: 10) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Front End Spoiler

Callout

Component Name

Preliminary Procedure

Lifting and Jacking the Vehicle (ATS-V)
Front Bumper Fascia Air Deflector Replacement - Outer (ATS-V Series)

Front End Spoiler Bolt (Qty: 10)

CAUTION:

Refer to Fastener Caution .

Tighten
2.5 N.m (22 lb in)

Front End Spoiler
