Diagnostic Aids
- The DIC displays SC when there is a shorted condition within the system.
- For intermittent diagnosis, refer to TESTING FOR INTERMITTENT AND POOR CONNECTIONS in Wiring Systems.
- Refer to AMBIENT AIR TEMPERATURE SENSOR RESISTANCE in order to verify the correct ambient temperature sensor readings.
