Diagnostic Aids
A faulty connection or and open ground circuit could result in Code 59. Use temperature-to-resistance table to check sensor at various levels to determine if sensor is out-of-calibration, which could result in firm shifts or TCC enable. Refer to TEMPERATURE-TO-RESISTANCE VALUES table.
