Internal Gearshift Mechanism (Vehicles equipped with an 2.3L engine)
WARNING: This page is about a different variant/trim than selected.
 Courtesy of FORD MOTOR COMPANY
|
| Item |
Description |
| Shift shaft assembly |
| 2 |
Reverse shift rail |
| 3 |
Reverse shift fork |
| 4 |
Shift fork pivot bolts |
| 5 |
1st/2nd shift rail |
| 6 |
1st/2nd shift fork |
| 7 |
3rd/4th shift rail |
| 8 |
3rd/4th shift fork |
| 9 |
5th/6th shift rail |
| 10 |
5th/6th shift fork |
| 11 |
Shift shaft stop pin |
| 12 |
Shift shaft detent |
| 13 |
Shift rail detents |
