Fuel Rail Pressure (FRP) Sensor: Removal

WARNING: This page is about a different variant/trim than selected.

NOTE: Removal steps in this procedure may contain installation details.

Refer to: FUEL SYSTEM PRESSURE RELEASE .
Refer to: BATTERY DISCONNECT AND CONNECT

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY
Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

Courtesy of FORD MOTOR COMPANY

WARNING: Fuel may remain pressurized in some fuel lines after the Fuel System Pressure Release procedure. Wear safety gloves and a face shield when disconnecting pressure lines to avoid skin and eye contact. Failure to follow this instruction may result in serious personal injury.

WARNING: Do not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.

NOTE: Make sure that the area around the component is clean and free of foreign material.

NOTE: Extreme cleanliness must be exercised when handling the component.

NOTE: The component must be installed by hand before final tightening.

Torque

: 24 lb.ft (33 Nm)

Courtesy of FORD MOTOR COMPANY
