Base IPC
| Item | Description |
|---|---|
| 1 | Tachometer |
| 2 | LH turn indicator |
| 3 | ABS warning indicator |
| 4 | Stability-traction control indicator (sliding car icon) |
| 5 | Stability-traction control disabled indicator (sliding car OFF icon) |
| 6 | Compass display area |
| 7 | TPMS warning indicator |
| 8 | MIL |
| 9 | Safety belt warning indicator |
| 10 | Outside air temperature display area |
| 11 | Air bag warning indicator |
| 12 | Electric park brake warning indicator |
| 13 | Brake warning indicator |
| 14 | RH turn indicator |
| 15 | Charging system warning indicator |
| 16 | Low oil pressure warning indicator |
| 17 | Speedometer |
| 18 | Fuel gauge |
| 19 | Low fuel indicator |
| 20 | Lights on indicator |
| 21 | High beam indicator |
| 22 | Main message center/trip display area |
| 23 | PRNDL display |
| 24 | Odometer display area |
| 25 | Cruise control message center indicator |
| 26 | Door ajar warning indicator |
| 27 | Fog lamp indicator |
| 28 | Powertrain malfunction indicator |
| 29 | Engine temperature gauge |
The base IPC provides a single 2.3" monochrome LCD message center display.
