Special Tool(s)

WARNING: This page is about a different variant/trim than selected.
SPECIAL TOOL DESCRIPTION

G07443054
 Remover, Halfshaft Oil Seal 308-428
G07443055
 Slide Hammer 100-001 (T50T-100-A)
  1. Remove the Power Transfer Unit (PTU). For additional information, refer to POWER TRANSFER UNIT (PTU)  in the service information.
  2. Using the Halfshaft Oil Seal Remover and Slide Hammer, remove the intermediate shaft seal from the left (transmission) side of the PTU  .
Fig 1: Removing Intermediate Shaft Seal From Left (Transmission) Side Of PTU
G07443056Courtesy of FORD MOTOR CO.
