Front Planetary Carrier Hub (Output Hub)
WARNING: This page is about a different car, the 2008 Mercury Sable, 2008 Ford Taurus X, and 2008 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
The front planetary carrier hub is splined to the front planetary carrier and the transfer shaft drive gear. This allows torque to be transferred from the planetary gearset to the final drive gearset.
| Item | Part Number | Description |
|---|---|---|
| 1 | 7N470 | Front planetary carrier |
| 2 | 7G142 | Front planetary carrier hub |
| 3 | 7F342 | Transfer shaft drive gear |
