Forward (1, 2, 3, 4) Clutch
WARNING: This page is about a different car, the 2008 Mercury Sable, 2008 Ford Taurus X, and 2008 Ford Taurus. However, it is still accessible from the selected car via links, so may be relevant.
The forward clutch is a brake clutch that holds the front sun gear and shell assembly. The forward clutch is applied in 1st, 2nd, 3rd and 4th gear.
Hydraulic pressure from the regulator valve in the valve body pushes the forward clutch piston against the forward clutch pack to apply the clutch. The forward clutch pack is pushed against the low OWC when it is applied. The rear sun gear and shell assembly is held stationary to the transaxle case as a result of the clutch being applied.
| Item | Part Number | Description |
|---|---|---|
| 1 | 7G148 | Low One-Way Clutch (OWC) snap ring |
| 2 | 7H253 | Low OWC |
| 3 | 7E311 | Forward clutch friction plates |
| 4 | 7E314 | Forward clutch steel plates |
| 5 | 7E457 | Forward clutch waved cushion spring |
| 6 | 7H365 | Forward clutch piston snap ring |
| 7 | 7B070 | Forward clutch piston return spring |
| 8 | 7A262 | Forward clutch piston |
| 9 | 7G304 | Front sun gear and shell assembly |
| 10 | 7005 | Transaxle case |
