Description & Operation
WARNING: This page is about a different car, the 2002 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:
Vehicles are equipped with air bag supplemental restraint system. Before attempting ANY repairs involving steering column, instrument panel or related components, see AIR BAG SAFETY PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM in AIR BAG RESTRAINT SYSTEMS
article in RESTRAINTS.
Horn system includes horn switch, horn relay, 2 horns, clock spring and Central Security Module (CSM). Multifunction switch is located on steering column and includes turn signals switch, hazard, flash-to-pass and windshield wiper/washer switches. Ignition switch and lock cylinder are also mounted on steering column. Steering column switch circuits are protected by maxi-fuses No. 102 (20-amp), No. 103 (50-amp), No. 111 (50-amp), No. 113 (50-amp) in battery junction box, and fuse No. 15 (5-amp) in central junction box. See Fig 1 and Fig 2 .
