Brake Fluid Reservoir: Installation

WARNING: This page is about a different car, the 2004 Dodge Dakota. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION: DO NOT any type of tool to install the grommets. Tools may cut, or tear the grommets creating a leak problem after installation. Install the grommets using finger pressure only.
  1. Lubricate new grommets with clean brake fluid and install grommets in cylinder body. See Fig 1.
  2. Start reservoir in grommets. Then rock reservoir back and forth while pressing downward to seat it in grommets.
  3. Install pins that retain reservoir to cylinder body.
  4. Fill and bleed master cylinder on bench before installation in vehicle. See MASTER CYLINDER BLEEDING  under BLEEDING BRAKE SYSTEM.
Fig 1: Installing Brake Fluid Reservoir
G00264478Courtesy of CHRYSLER CORP.
