Removal - Rear Rotor
WARNING: This page is about a different car, the 2005 Dodge Stratus and 2005 Chrysler Sebring. However, it is still accessible from the selected car via links, so may be relevant.
- Raise vehicle. (Refer to LUBRICATION & MAINTENANCE/HOISTING - STANDARD PROCEDURE)
- Remove rear tire and wheel.
- Remove the caliper and shoes from adapter and hang out of way. (Refer to BRAKES/HYDRAULIC/MECHANICAL/BRAKE PADS/SHOES - REMOVAL)
- Remove any clips on the wheel mounting studs.
- Remove rotor from hub. See Fig 1.
| 1 - BRAKING DISC |
| 2 - DISC SHIELD |
| 3 - HUB |
| 4 - DRUM-IN-HAT PARKING BRAKE |
