Special Tools

WARNING: This page is about a different car, the 2022 Cadillac CT4. However, it is still accessible from the selected car via links, so may be relevant.

DT-36850 Transjel Lubricant

Equivalent regional tools: Special Tools

Courtesy of GENERAL MOTORS COMPANY

Automatic Transmission Case Extension Seal (1) - Install NEW
Apply DT-36850 Transjel Lubricant to the inner part of the output shaft seal where the output shaft rides before installing the extension onto the transmission.

CAUTION:

Before installing the transmission case extension to the transmission case, make certain all internal transmission components including the stator shaft support assembly and output carrier are in place. Failure to do so may result in damage to the transmission.

Automatic Transmission Case Extension (2) - Install
Automatic Transmission Case Extension Bolt (3) - Install and hand tighten [6x]

CAUTION:

Refer to Fastener Caution .

Automatic Transmission Case Extension Bolt (3) - Tighten in sequence - Fastener Specifications
