Installation Procedure
WARNING: This page is about a different car, the 2019 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
Air Conditioning Condenser Bracket (1) @ Radiator - Install
Air Conditioning Condenser (1) @ Air Conditioning Condenser Bracket - Install
- Connect the electrical connector.
Radiator Air Lower Baffle and Deflector (1) - Install - Radiator Air Upper Baffle and Deflector Replacement (LFV, LTG)
Radiator Air Upper Baffle and Deflector (1) - Install - Radiator Air Upper Baffle and Deflector Replacement (LFV, LTG)
Air Conditioning Evaporator Tube (1) @ Air Conditioning Condenser Assembly - Install - Air Conditioning Evaporator Tube Replacement (LFV, LTG)
- Recharge the refrigerant. Refrigerant Recovery and Recharging (R-1234yf)
