Exhaust Manifold Removal - Left Side
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Spark Plug Wires |
| 2 | Heat Shield Bolt |
| 3 | Heat Shield |
| 4 | Exhaust Manifold Bolt |
| 5 | Exhaust Manifold |
| 6 | Exhaust Manifold Gasket Refer to Replacing Engine Gaskets . |
