Removal Procedure
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the rear door trim panels in order to gain access the rear window. Refer to Rear Door Trim Panel Replacement - Left Side (E24) , and Rear Door Trim Panel Replacement - Right Side (E24) .
- Cover to protect the following parts from broken glass:
- The upper dash pad.
- The defroster outlets and A/C outlets
- The seats and carpeting.
- NOTE:
Keep the cutting edge of the tool against the window. This will allow the urethane adhesive to be separated from the window.
- Leave a base of urethane on the pinchweld flange.
- The only suitable lubrication is clear water.
- Use J 24402-A glass sealant remover (cold knife), J 39032 stationary glass removal tool or equivalent in order to remove the window.
With the aid of an assistant, use the suction cups to lift the rear window from the opening.
Remove the stationary window.
WARNING:
Refer to Cracked Window Warning .
NOTE:
Before cutting out a stationary window, apply a double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
WARNING:
Refer to Defroster Outlet Warning .
