Removal Procedure

WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the sliding side door upper roller bracket cover. Refer to Rear Side Door Upper Roller Bracket Garnish Molding Replacement .
  2. Remove the sliding side door upper track garnish molding. Refer to Rear Side Door Upper Track Garnish Molding Replacement .
  3. Remove the sliding door garnish molding. Refer to Rear Side Door Garnish Molding Replacement .
  4. GM334049Courtesy of GENERAL MOTORS COMPANY

    Remove the bolts that retain the upper roller bracket to the door.

  5. Remove the sliding side door upper roller bracket from the rear of the upper track.
  6. Remove the sliding side door upper roller bracket from the vehicle.
