Radio Rear Speaker Replacement - Lower
WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Rear Door Trim Panel Replacement - Left Side (E24) , or Rear Door Trim Panel Replacement - Right Side (E24) |
|
| 1 | Rivet [3x]
WARNING:
Procedure Drill out the rivets. |
| 2 | Radio Rear Speaker Procedure Disconnect the electrical connector. |
