Front Bearing Installation

WARNING: This page is about a different variant/trim than selected.
GM2828287Courtesy of GENERAL MOTORS COMPANY
NOTE: Callouts in the following chart represent components shown in graphic above.
Front Bearing Installation

Callout Component Name
1 Counter Gear Front Bearing Assembly

Procedure

  1. Install the counter gear front bearing, using the DT 25234  gear and bearing installer with a hydraulic press.

Special Tools
DT 25234  Gear and Bearing Installer
For equivalent regional tools, refer to Special Tools (M13) .
