Clutch Actuator Cylinder Pipe Elbow Replacement
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
|
WARNING:
Refer to Brake Fluid Irritant Warning .
CAUTION:
Preliminary Procedure Without draining the coolant or removing the hoses, remove and position aside the radiator surge tank. Refer to Radiator Surge Tank Replacement
.Refer to Brake Fluid Effects on Paint and Electrical Components Caution . |
|
| 1 | Clutch Actuator Cylinder Front Pipe Retaining Clip |
| 2 | Clutch Actuator Cylinder Pipe Elbow Retaining Clip |
| 3 | Clutch Actuator Cylinder Pipe Elbow Procedure After installation is completed. Bleed the hydraulic clutch system. Refer to Hydraulic Clutch System Bleeding . |
